Non-pressurizedステンレス鋼の太陽間欠泉

Non-pressurizedステンレス鋼の太陽間欠泉

Non-pressurizedステンレス鋼の太陽間欠泉
カタログ非- 加圧太陽熱温水器
アルバム拡大表示
タイプ避難させた管
圧力減圧された
循環のタイプ間接/閉じたループ(活動的な)
暖房装置Thermosyphon (受動)
結合方式指示プラグ
取付け支えがない
ハウジング材料ステンレス
証明セリウム
容量300
銘柄INLIGHT
銘柄INLIGHT
適用シャワー
容量400
型式番号INLIGHT-N
包装外の輸出カートンのパッキングが付いている内部の多袋
単価US $ 100-400 / set
更新時間2019-11-20
詳細情報

Stainless Steel Solar Geyser  Technical Parameters:

  Vacuum tube

 Spec.(mm)

  Φ47×1500    Φ58×1800    Φ70×2000

 Tube (pcs)

  12 / 15 / 16 / 18 / 20 / 22/ 24 / 28 / 30 / 36 / 42

 Material

  3.3 Borosilicate glass, magnetron spluttering selective coating

 Coating

  AL/AL-ALN(H)/AL-ALN(L)/ALN or Cu/SS-ALN(H)/SS-ALN(L)/ALN

  Water tank

 Capacity

  70 ~ 400L for inner water tank

 Inner tank

  Food-grade stainless steel plate SUS304-2B

 Insulation

  High-density polyurethane integrated foam-forming 50~60mm

 Tank shell

  Color steel plate

   Bracket

 Spec.(mm)

  1.2 ~ 1.5mm thickness

 Material

  Hot-dip galvanized steel plate

   Accessories

 Stainless bolts & nuts, Silicon rubber seal, Dustproof rubber seal, Plastic pipe holder

 Optional device

 Electrical heater, Intelligent controller / Assistant tank, Anod magnesium bar

    Tilt  angle

 25°~ 50°

  Water output

 45-95oC

Hail resistance

 Φ25mm diameter



Stainless Steel Solar Geyser  Features description:

Non-pressurized solar water heater is such a most economical system with high efficiency at the same time. It works depending on the gravity of water, so it's much better to be installed on the slope or flat roof as top as possible to get enough hydraulic pressure for shower. A simple assistant tank can be equipped for tap water refill automatically or with an intelligent controller to control the auxiliary heating device and water refill at the same time.



Vacuum tube: Hail-resisting 3.3 borosilicate glass with high-tech single-target selective coating ensures an efficient solar collecting, tri-target vacuum tube with its patent interference coating makes the efficiency not only improved by 12% but also with a 380oC high temperature resistantce without peeling off the coating layer.



Inner water tank: Food-grade stainless steel SUS304-2B as inner tank keeps the water clean and drinkable, together with advanced argon arc welding technics to ensure it with a long lifespan (more than 15 years).



Water tank shell: Imported color steel plate, with its special coating treatment ensures a long life even to ocean coast weather.

Insulation Layer: High-density polyurethane integrated foam-forming with twice slaking treatment, preserves hot water temperature as long as 70~80 hours.



Supporting Bracket: Very strong hot-dip galvanized steel plate with a good weight bearing and wind resistance design (140 km/hr), painting or baking process ensures a super mechanical performance and corrosion resistance, easy installation, universal bracket suitable for either flat and slope roof installation.

Accessories: Stainless bolts & nuts, water-proof silicon rubber, anti-aging dustproof rubber seal, plastic pipe holder and ventilating cap to ensure their lives as long as other parts of the system


Optional Devices

Assistant tank,  automatically feed tap water into storage tank to keep it sufficient always

Electrical heater, as an auxiliary heating element in case of raining or cloudy days so as to ensure a continous hot water supply

Intelligent controller, automatically controls water refill and startup of auxiliary heating device, more intelligent system operation



Warranty: 3 years international responsibility for integrated system exchange and 15 years for glass vacuum tube compensation due to original quality problems
